Mini-pleated V-Bank filters
HIGHFIL:Mini-pleated V-Bank filters
Series: V-Bank Series
Frame: ABS
Separators: Hot Melt
Media: Glass Fibre
Sealant: Polyurethane
Temperature: <70oC
Humidity: <100% RH
Efficiency: H10 (EN1822) > 95%
MPPS: >95% (H11); DOP: >95% @ 0.3μm
MPPS: >99.95% (H13); DOP: >99.97% @ 0.3μm
MPPS: >99.995% (H14); DOP: >99.99% @ 0.3μm
Recommended final Pressure Drop: < 600Pa
